How to Build Real-Time Webhook Workflows with n8n (Trigger, Route, and Respond to Any Event)

Polling Is Dead. Webhooks Are How Events Actually Happen.

Schedule triggers are useful for batch jobs. But for anything time-sensitive — a payment completed, a form submitted, a GitHub push, a support ticket opened — checking every few minutes is the wrong architecture.

Webhooks let the event source push data to your workflow the instant something happens. No polling lag, no wasted API calls, no missed events between check intervals.

n8n's Webhook node turns any HTTP POST into a workflow trigger. One endpoint handles Stripe payment events. Another routes GitHub CI failures. Another processes Typeform submissions — all in real time, all automated.

What You Can Automate With Webhooks

Webhooks work wherever an external system can fire an HTTP request:

• Payment events — Stripe payment_intent.succeeded, charge.failed, customer.subscription.deleted
• Form submissions — Typeform, Tally, Webflow, or any form tool that POSTs on submit
• Git events — GitHub or GitLab push, pull request opened, CI run failed
• Support tickets — new ticket in Zendesk, Intercom, or Freshdesk
• E-commerce events — Shopify order created, inventory low, refund requested
• Auth events — new user signed up via Auth0, Clerk, or Supabase
• Inbound messages — Slack slash commands, Telegram bot messages, SMS from Twilio
• Custom product events — any event your app backend fires via a single HTTP call

The Webhook Pipeline

A production-grade n8n webhook workflow follows this shape:

Webhook Trigger (POST /webhook/<id>)
  → Code (validate signature, parse + normalize payload)
  → Switch (route by event_type)
    → payment_succeeded:    Sheets (log) → Gmail (receipt) → Slack (alert)
    → payment_failed:       Gmail (dunning email) → Slack (urgent alert)
    → subscription_deleted: Gmail (offboarding) → CRM (update status)
    → unknown_event:        HTTP Request (log to dead-letter endpoint)
  → Respond to Webhook (200 OK)

Every event arrives at a single endpoint, gets validated and parsed, gets routed to the right action, and gets acknowledged — all within a few hundred milliseconds.

1. Collect — Expose the Webhook Endpoint

The Webhook node gives you an instant HTTPS endpoint. Set the HTTP method to POST and copy the production URL from the node settings panel.

Paste that URL into Stripe's webhook dashboard, Typeform's notification settings, GitHub's repository hooks, or anywhere that accepts a webhook target.

The node passes the full request to the next node: body, headers, query params, and raw body (important for signature verification).

2. Process — Validate and Normalize

Before routing, a Code node does two things.

Signature check — most services sign the payload so you can verify it's genuine:

const crypto = require("crypto");
const secret = "YOUR_WEBHOOK_SECRET";
const signature = $input.first().headers["stripe-signature"];
const rawBody = JSON.stringify($input.first().body);

const expected = crypto
  .createHmac("sha256", secret)
  .update(rawBody)
  .digest("hex");

if (!signature.includes(expected)) {
  throw new Error("Invalid webhook signature — request rejected");
}

return $input.all();

Normalization — extract the fields every downstream node needs:

const body = $json.body;
return [{
  json: {
    event_type:     body.type,
    event_id:       body.id,
    customer_email: body.data?.object?.customer_email ?? "",
    amount_cents:   body.data?.object?.amount ?? 0,
    currency:       body.data?.object?.currency ?? "usd",
    created_at:     new Date(body.created * 1000).toISOString()
  }
}];

3. Route — Branch by Event Type

A Switch node reads event_type from the normalized payload and routes to the correct branch.

Keep routing logic in the Switch node — not in nested IFs inside a Code node. One condition per branch, one branch per event type. Unknown event types go to a dead-letter branch that logs the raw payload for debugging.

Switch (event_type)
  → "payment_intent.succeeded"      → payment success branch
  → "payment_intent.payment_failed" → payment failure branch
  → "customer.subscription.deleted" → cancellation branch
  → default                         → HTTP Request (POST /logs/unhandled-events)

4. Act — Execute the Right Response

Each branch runs its own action sequence. A payment success branch might:

1. Google Sheets — append a row to the revenue log
2. Gmail — send the customer a payment receipt
3. Slack — post a payment alert to #payments
4. HTTP Request — call your CRM API to tag the contact as paying

A payment failure branch does different things:

1. Gmail — send a dunning email with a payment retry link
2. Slack — post an urgent alert to #billing-alerts
3. Google Sheets — log the failure with retry count for follow-up tracking

5. Follow Up — Acknowledge the Sender

The final node in every branch is a Respond to Webhook node.

Stripe requires a 200 OK within 30 seconds or it retries the event. Slack slash commands require a response within 3 seconds or they show a timeout error.

{
  "received": true,
  "event": "payment_intent.succeeded"
}

Set the HTTP status code to 200. If your workflow errored, n8n returns a non-200 automatically — the sender retries, and the failure appears in your execution log.

Implementation Patterns

Pattern 1 — Multi-Event Single Endpoint

One endpoint handles all event types from a single service:

Webhook (POST /stripe-events)
  → Code (verify signature, extract event_type)
  → Switch (event_type)
    → payment_succeeded:        log + receipt email + Slack alert
    → payment_failed:           dunning email + urgent Slack alert
    → subscription_created:     welcome sequence trigger
    → subscription_deleted:     offboarding sequence trigger
    → invoice_upcoming:         payment reminder email
    → default:                  log to unhandled-events sheet

One URL in Stripe's dashboard. All events flow through one validation step. Adding a new event type means adding one Switch branch — nothing else changes.

Pattern 2 — Cross-Service Fan-Out

One incoming event triggers actions across multiple services simultaneously:

Webhook (POST /new-signup — from your product backend)
  → Code (parse: email, plan, source)
  → [parallel branches]
    → Branch A: HTTP Request (create HubSpot contact)
    → Branch B: Gmail (send welcome email)
    → Branch C: Slack (alert #sales with plan and source)
    → Branch D: Google Sheets (log to onboarding tracker)
  → Respond to Webhook (200 OK)

n8n runs the parallel branches concurrently. All four actions complete before the final response node fires.

Pattern 3 — Webhook-to-Queue for Heavy Processing

When the event triggers work that takes more than a few seconds:

Webhook (POST /export-requested)
  → Code (extract: user_id, export_type, filters)
  → Google Sheets (append row: status=pending, requested_at=now)
  → Respond to Webhook (202 Accepted)

[Separate workflow — Schedule Trigger every 2 minutes]
  → Sheets (rows where status=pending)
  → HTTP Request (call export API — may take 5-30s per row)
  → Code (build download link from response)
  → Gmail (send download link to user)
  → Sheets (update row: status=complete)

The webhook responds immediately with 202 Accepted. The heavy work runs in a background workflow that never blocks the HTTP response.

The Data Entry Hub template uses a similar queue pattern — webhooks write to a central sheet, a separate workflow processes each row on a schedule.

n8n Nodes You'll Use Most

Getting Started

1. Pick one event source and one event type — start with Stripe payment_intent.succeeded or a Typeform submission. One service, one event.
2. Create the Webhook node — set method to POST, copy the production URL.
3. Register the URL — paste it into the service's webhook settings. Enable test mode if available.
4. Fire a test event — use the service's "send test" button. Watch the n8n execution log to see the raw payload structure.
5. Add the Code node — implement signature verification and normalization using the real field paths from the test payload.
6. Add the Switch node — one branch for the event type you're handling. Add a default branch that logs unknowns to a Google Sheet.
7. Build the action branch — wire up Sheets, Gmail, Slack, or your CRM. Add a Respond to Webhook node at the end of every branch.

Once the first event type is working end to end, adding branches for additional event types is fast — the validation and routing infrastructure already exists.

For workflows that send emails or Slack messages as part of their response, see n8n email inbox automation and n8n Slack automation. For handling the data that webhook events write to spreadsheets, see the guide to n8n data reporting automation.

If you're building a subscription billing pipeline on top of Stripe webhooks, the Smart Subscription Manager and Email Follow-up Automator templates give you a working starting point with the routing logic already wired up.
